Britax BFR1000 25 Watt Rotating LED Beacon

Britax BFR1000 25 Watt Rotating LED Beacon

Brand: Britax
Origin: USA


25 Watt Rotating LED Beacon, Die-cast Alloy Base, SAE J845 Class 1

Introducing the Britax BFR1000 rotating LED beacon! Featuring unique CyclOne LED Technology with high reflectivity free-form rotating reflector and two rotation speeds and directions.

Features and Benefits

  • Unique CyclOne LED Technology
  • High reflectivity free-form rotating reflector
  • Two rotation speeds at 120rpm and 180rpm (user selectable)
  • Selectable rotation direction (clockwise, anti-clockwise)
  • 30% dimmable mode for night use (user selectable, bolt base only)
  • Gasket sealed tough polycarbonate lens with smooth exterior
  • Gel-filled heavy duty die-cast alloy base
  • Bolt base: three-hole ISO footprint, rubber mounting gasket
  • Bolt base: bottom or side entry power cable, stainless steel fittings
  • Magnetic base: 1–3 metre curly cord, cigarette and merit plug
  • SAE J845 Class 1 beacon, EMC: R10, RCM, IP67

BFR1000 Specifications

Voltage10-30V Multivoltage
AmperageMax 2.0A @ 12V DC, Avg 1.3A @ 12V DC
GlobeLED
Lens MaterialPolycarbonate
BaseDie-cast Alloy
MountingThree Bolt, Suction Magnetic
SeriesBritax BF Series LED Beacons
DimensionsH 142mm x Ø 148.5mm
ApprovalsRCM, SAE Class 1, All categories, EMC ECE R10, IP67 Rated
Lens ColourAmber
BrandBritax
ApplicationHeavy Duty

Specification Sheets


Applications: Heavy Duty Machinery, Mining, Vehicles, Trucks


Dimensions:
Width: 7.48" (190 mm), Height: 5.98" (152 mm)

Part#
Description
