Grote 64M11-5

Grote 64M11-5

Brand: Grote
Origin: USA

Click for:

Grote’s LED Radius Light – Rugged, dependable coverage for safety and security.

The LED Radius Light attaches to a vertical surface above an entrance or exit and distributes light over a large area to help prevent injuries during evening or early morning deliveries. Made to work on either 12v or 24v systems, the Radius Light illuminates a minimum of 12 feet (4 meters) in three different directions while providing up to 10 lux. These features allow the employee not only to see obstructions underfoot but also provide lighting to read instructions.

The new LED Radius light is a solid, bright solution for the exterior application. Constructed of heavy-duty, corrosion-resistant, die-cast aluminium housing, the low profile light’s design protrudes only 2.5 in. from the vehicle surface, allowing for increased light output and lamp longevity.

Reverse polarity protection and over-voltage protection to prevent voltage spike damage. Includes Spacer with 0.642 inch depth and Gasket used for surface mounting. (Spacer designed for extended installation and wire routing)

Grote 64M11-5 Features & Benefits

  • Tough, durable, and lightweight cast aluminium housing
  • Six-200 lumen LEDS that produce daylight-like visibility
  • TIR Lens for efficiently distributed lighting
  • Bi-Voltage System for 12 volt and 24 volt systems
  • Vibration, dust, corrosion, and moisture resistant

Grote 64M11-5 Specifications

Housing MaterialCast Aluminum
Voltage12-24V DC
AMP1.5 @ 12V / 0.75 @ 24V
Ingress ProtectionIP69K
OutputLumens: 1200 Instant On / 1100 Effective
Ratings and CompliancesIngress Protection: IP69K
MIL-STD-202G (Vibration)
SAE J575-4.14 (Chemical Resistant)
SAE J2139-4.4 (Corrosion)
SAE J2139 (Humidity/Temperature)

Grote 64M11-5 Specifications Flyer (PDF)

Width: 1.67" (42.37 mm), Height: 1.56" (39.6 mm), Length: 10.96" (278.35 mm)
