Brand:
J.W. Speaker
Origin: USA
Click for:
J.W. Speaker has now taken their anti-glare technology to the next level with the new dual-white anti-glare beam pattern for the Model 526 6 x 6″ heavy-duty LED work light. In your choice of black or yellow die-cast aluminum housing, this dual white version features a wiring toggle configuration that allows the setup of the light colour temperature for 2800K warm white or 5000K cool white. Using warmer lights can be less harsh on the eyes for operators, reduce glare in dusty and foggy and also reduce the overall light pollution in the mine site.
J.W. Speaker Model 526 Dual White Anti-Glare LED Work Light Features & Benefits ▲
- Choice of Yellow or Black Die-cast Aluminum Housing sealed to IP69K
- Dual White Anti-Glare beam pattern
- 24 Volt Versions are available for Theft Deterrence
J.W. Speaker Model 526 Dual White Anti-Glare LED Work Light Specifications ▲
| Type | LED Work Light |
| eLumens | 3,464 Lu (Cool White), 3,390 Lu (Warm White) |
| rLumens | 9,900 Lu (Cool White), 7,500 Lu (Warm White) |
| Candela Output | 4,480 (Cool White), 4,508 (Warm White) |
| Beam Pattern | Anti-Glare Beam |
| Curren Draw | 3.25A @ 24V DC (Cool White), 3.25A @ 24V DC (Warm White) |
| Input Voltage | 24V DC |
| Operating Voltage | 16-32V DC |
| Minimum Operating Temperature | -40 °C / -40 °F |
| Maximum Operating Temperature | 65 °C / 149 °F |
| Housing Material | Die-Cast Aluminum |
| Housing Color | Yellow (1300571) or Black (1300641) |
| Outer Lens Material | Polycarbonate |
| Outer Lens Color | Clear |
| Connector or Wiring | iCONN connector - IMate23 3 wire |
| IP Rating | IEC IP69K |
| Mounting | Universal Pedestal Mount |
| Weight | 4.60 lbs / 2.09 kgs |
| Shipping Weight | 4.88 lbs / 2.21 kgs |
| Warranty | 5 Years |
| Additional Information | Warm/Cool White Color Temperatures: Warm White: 2800K Cool White: 5000K |
J.W. Speaker Model 526 Dual White Anti-Glare LED Work Light Specification Flyer (PDF) ▲
Applications: Construction, industrial, material handling, mining, railroad, specialty vehicles, agriculture, automotive and off-road 4x4
Dimensions:
Width: 6.2" (157.48 mm), Height: 6.3" (160.02 mm), Depth: 3.8" (96.52 mm)
J.W. Speaker Model 526 Dual White Anti-Glare LED Work Light Parts Enquiry ▲
24V LED Work Light with Yellow Housing, Polycarbonate Lens & Dual White Anti-Glare Beam Pattern
24V LED Work Light with Black Housing, Polycarbonate Lens & Dual White Anti-Glare Beam Pattern
2.5M 18AWG iCONN iMATE 23 Wire Asm w/DT04-2P
15M 18AWG iCONN iMATE 23 Wire Asm w/DT04-2P
