Brand:
J.W. Speaker
Origin: USA
Click for:
Adjustable Mount (left) and Fixed Panel Mount (right)
4.5″ Round LED Headlights
The Speaker 8415 has been updated to an Evolution Series solution, delivering even better performance with a new, lightweight yet durable platform. Designed for OEMs and aftermarket customers alike, these powerful round LED headlights include a custom version that meets UL standards for industrial use.
J.W. Speaker 8415 Evolution 4.5″ Round LED Headlights Features & Benefits ▲
- High performance optics with increased high beam intensity
- New high-impact, corrosion-resistant Xenoy housing
- Custom version with polycarbonate housing designed for industrial applications needing UL requirements
- Improved thermal management using thermoplastic technology found in the Speaker XD work light series
- Adjustable or fixed mounting options
J.W. Speaker 8415 Evolution 4.5″ Round LED Headlights Specifications ▲
| Light source | LEDs |
| Colour Temperature | 5000K |
| eLumens | 720 Lu (high beam); 240 Lu (low beam) |
| rLumens | 1,075 Lu (high beam); 430 Lu (low beam) |
| Beam Pattern | Forward Lighting - high beam (DOT/ECE) Forward Lighting - low beam (DOT) Forward Lighting - low beam (ECE right-hand) |
| Current Draw | 1.14A @ 12V DC (high beam) 0.41A @ 12V DC (low beam) 0.57A @ 24V DC (high beam) 0.22A @ 24V DC (low beam) |
| Voltage | 12-24V DC |
| Operating Temperature | -40°C to +65°C |
| Shape | Round |
| Housing | Black Xenoy |
| Lens | Hardcoated polycarbonate |
| Lens Colour | Clear |
| Electrical Connection | PE 12110293 |
| IP Rating | IP67 |
| Mounting | Adjustable Mount, Fixed Panel Mount, Adjustable Mount - UL Version |
| Additional Information | Adjustable mount needed for larger vehicles in order to modify pattern as needed |
| Ratings | SAE J1623, SAE J2258, ASABE S608, ECE Reg 113 Class C |
| Weight | N/A |
| Dimensions (DxWxH) | 2.87x4.39x4.7" (73x111.5x119.6mm) |
J.W. Speaker 8415 Evolution 4.5″ Round LED Headlights Specification Flyer (PDF) ▲
Dimensions:
Width: 4.39" (111.5 mm), Height: 4.7" (119.6 mm), Depth: 2.87" (73 mm)
J.W. Speaker 8415 Evolution 4.5″ Round LED Headlights Parts Enquiry ▲
8415 Series 12-24V DOT / ECE LED Headlight, Xenoy housing, Universal Mount (adjustable)
8415 Series 12-24V DOT / ECE LED Headlight, Xenoy housing, Rigid Mount (fixed panel)
8415 Series 12-24V DOT / ECE LED Headlight, Polycarbonate housing, Universal Mount (adjustable)
