Vision X LUC90 AC 420W Heavy-duty Dragline/Shovel Light

Vision X LUC90 AC 420W Heavy-duty Dragline/Shovel Light

Brand: Vision X
Origin: USA


Click for:

This 420W LED heavy-duty fixture has been designed to an OEM standard and not to a compromise. LUC90 is engineered to thrive in the most demanding environments on draglines and shovels to ensure you have the light output and durability to illuminate the mining face. Producing 54,000 eLumens from only 420W, the LUC90 with its P&H designed dragline bracket is the right choice for stacker/reclaimers, crushers, draglines and shovels.




Vision X LUC90 AC 420W Heavy-duty Dragline/Shovel Light Features & Benefits

  • Engineered for demanding environments
  • 54,000 eLumens from only 420W
  • Heavy-duty P&H designed dragline bracket
  • Designed to an OEM standard and not to a compromise



Vision X LUC90 AC 420W Heavy-duty Dragline/Shovel Light Videos



Vision X LUC90 AC 420W Heavy-duty Dragline/Shovel Light Specifications

Type90 x XP-LHD (CREE) LEDs
Lumens54,000 eLumens
Beam PatternsSpot 10° (SD), Narrow 25° (ND), Medium 40° (MD),
Flood 60° (FD), Wide Flood 90° (WD)
Color Temperature5000K
Voltage90-305V AC,
415V AC (2 phase)
Wattage420W
Current Draw1.22A @ 115V AC, 0.61A @ 230V AC, 0.51A @ 277V AC
Operating Temperature-40°C to +60°C
Vibration15.6Grms
IP RatingIP68, IP69k
Certifications/RatingsEMC Emission: EN55015, EN55022 (CISPR22) Class B,
EN61000-3-2, Class C (@Load ≥ 50%); EN61000-3-3.
EMC Immunity: EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024,
Light Industry Level surge immunity Line-Earth 4KV, Line-Line 2KV
Short CircuitConstant current limiting, recovers automatically after fault condition is removed
MountingDragline bracket
HousingDie-Cast 6061 Aluminium, Grey in colour
LensPolycarbonate Lens
Weight88 lbs (40kg) including dragline bracket
Dimensions (DxWxH)7.2x23.5x14.2” (182x596x361mm)
WarrantyExtended warranty

Vision X LUC90 AC 420W Heavy-duty Dragline/Shovel Light Specifications Flyer (PDF)


Applications: Draglines, shovels, heavy industrial, stackers/reclaimers, crushers, cranes
