Brand:
J.W. Speaker
Origin: USA
The JW Speaker 9800 12-24V DOT LED Non-Heated Headlight – 2 Light Kit is designed to provide a universal, multi-function headlight for on-highway use. This all-in-one, low-profile, bolt-on solution delivers a level of flexibility that makes it an excellent headlight choice for nearly any vehicle, including applications in: agriculture, construction, mining, specialty trucks, trucks and buses.
Features and Benefits
- 2,880 raw lumens (high beam); 2,160 effective lumens (high beam)
- 1,150 raw lumens (low beam); 800 effective lumens (low beam)
- Beam Pattern(s): Forward Lighting (high beam), (DOT/ECE), Forward Lighting DOT (low beam), Signalisation – Turn (Front)
- UV-resistant polycarbonate lens
- Xenoy housing provides maximum protection
- Rugged solid state LEDs can withstand shock & vibration
- Universal pedestal mount
- Mounting Hardware: (x4) M8 – 1.25-80 mm x 25 mm SS carriage bolt
- 6-Pin Delphi connector
Speaker 9800 LED Non-Heated Headlight – 2 Light Kit Specifications
| Light source | LEDs |
| eLumens | 1,150 Lu (high beam); 800 Lu (low beam) |
| rLumens | 2,880 Lu (high beam); 2,160 Lu (low beam) |
| Beam Pattern | Forward Lighting DOT/ECE (high beam) Forward Lighting DOT (low beam) Signalisation (front turn) |
| Current Draw | 3.60A @ 12V DC (high beam) 2.70A @ 12V DC (low beam) 0.85A @ 12V DC (turn signal) 0.10A @ 12V DC (DRL) |
| Voltage | 12-24V DC |
| Housing | Xenoy |
| Lens | Clear polycarbonate |
| Mounting Hardware | (x4) M8 - 1.25-80 mm x 25 mm SS carriage bolt |
| Mounting Type | Universal pedestal mount |
| IP Rating | IP67 |
| Wiring | 6-Pin Delphi |
| Weight | 15 (lbs) / 6.8 (kgs) |
| Dimensions (DxWxH) | 5.24x11.48x3.72” (133.2x291.6x94.5mm) |
Specification Sheets
Applications: Agriculture, Construction, Mining, Specialty Trucks, Trucks and Buses
Dimensions:
Width: 11.48" (291.6 mm), Height: 3.72" (94.5 mm), Depth: 5.24" (133.2 mm)
