Brand:
Vision X
Origin: USA
Click for:
Note: USA Customers Only (not available for export)
The VL Series LED Light offers outstanding light output in a functional design that adjusts with the single bolt bracket. High-quality construction and components enable the VL-Series LED Light Duty to withstand vibration up to 21 Grms. Built-in reverse polarity protection helps prevent accidental damage caused by incorrect installation. A high-value light, this series is designed for many light-duty commercial applications.
Vision X VL-Series 3 LED Light Features & Benefits ▲
- 5W CREE LEDs
- 9-32 Volts
- CISPR 25 Class 3
- Reverse Polarity Protection
Vision X VL-Series 3 LED Light Specifications ▲
| Fixture Weight | 1.1lbs (0.5kg) |
| Connector | None or Deutsch DT04-2P |
| Mounting | Single Bolt |
| LED | 5W Cree |
| rLumens | 1140 lm |
| eLumens | 797 lm |
| Wattage | 15W |
| Amp Draw | 1.25A @ 12V |
| Color Temperature | 6000K |
| Operating Voltage | 9-32V DC |
| Operating Temperature | -40°C ~ 60°C |
| Lifespan | 50,000hrs |
| Polarity | Reverse Polarity Protection |
| Housing Material | Aluminum |
| Lens | Polycarbonate |
| Finish | Powder Coated Gloss |
| EMC Emission | Compliance to EN55022, EN61000-3-2, Class A , EN61000-3-3 |
| EMC Immunity | Compliance to EN55024, EN61000-4-2,3,4,5,6,8,11; light industry level (surge 2KV), criteria A |
| Ingress Protection | IP68, IP69K |
| Vibration Rating | 21Grms |
| Warranty | 1 Year |
Vision X VL-Series 3 LED Light Specifications Flyer (PDF) ▲
Vision X VL-Series 3 LED Light Parts Enquiry ▲
Vision X VL-Series 3 LED Light: Powder-coated, Deutsch Connector included
Vision X VL-Series 3 LED Light: Powder-coated, Deutsch Connector not included
Vision X VL-Series 3 LED Light: Stainless Steel, Deutsch Connector included
Vision X VL-Series 3 LED Light: Stainless Steel, Deutsch Connector not included
